JP22是我公司引進德國技術制造的一款小型機械，設有水泵與水計量功能；具有自動攪拌、泵送、粘結、噴涂聯合作業功能，適應各類不同特性與不同用途預拌干混砂漿施工，包括內外墻砂漿、保溫砂漿、自流平砂漿、粘接砂漿、修補砂漿等；設置壓力控制保護機構，實現遠程控制操作；模塊式結構，拆裝方便，結構緊湊；體積小，移動方便，適應狹窄空間使用。

     JP22 is small machine introduced German technology. It sets water pump and water measuring function. It has the combined function of automatic mixing, pumping, bonding, plastering. It’s suitable for construction of different characteristics and use of dry ready-mixed mortar including internal and external wall mortar, thermal insulation mortar, self-leveling mortar, bonding mortar, repairing mortar etc. It sets the pressure controlling protection mechanism and achieves the remote control. With modular and compact structure, it's easy to dissemble. Due to its small volume, it's easy move and adapt for use in narrow spaces.

標準配置Standard equipment

混合區料斗Mixing hopper

泵設備Pump equipment      Wenggong D40

水壓泵Water pressure pump

齒輪馬達Gear motor  RF57-Y4KW

帶快速連接器空氣管Air tube with fast connector  ID:￠13  Length:10m

防震壓力計總成    Shockproof pressure gage assembly  YN60-6Mpa

輸漿管Delivery hose     GB/T3683 25-1-W.P或

                                   GB/T3683 32-1-W.P.9Mpa  Length:10m

帶有氣源支持噴槍Spraying gun with air support（配噴嘴with spraying nozzle）

水量電樞控制集成Water volume armature control integration  LZS-15 100-1000L/h

工具箱Tool box

操作說明書Operating instruction

   JP22型砂漿噴涂機技術參數

   Technical parameters of JP22 Mortar plastering machine

   電源Supply power                                                 400V  50Hz

   電機功率Motor power                                             4.0  2.2kw

   **大顆粒尺寸Maximum grain size                             4mm

   排量Output                                                         25L/min

   輸送壓力Delivery pressure                                      40bar

   水平輸送距離Horizontal delivery distance                  40m

   垂直輸送距離Vertical delivery distance                      15m

   送料斗容量Hopper volume                                       50L

   重量Net weight                                                    185kg

   外型尺寸Dimension (L×W×H)                                 1200*660*1100mm

 注：以上數據只作參考，因選用砂漿的理化性能差別，其產生的各項數值也不相同。

Note: The above figures are only for reference, due to differences in physical and chemical properties of selected mortar, its each value is different accordingly.
