| 包裝規格 | 25公斤/桶 |
|---|---|
| 產地 | 河北邢臺 |
| 粒度 | 300目 |
| 牌號 | 中洲合金 |
| 品名 | 鎳基合金粉 |
| 形狀 | 顆粒狀 |
| 制作方法 | 霧化法 |
| 鎳含量≥ | 80 |
產品特性：Ni45是硬度適中的合金粉末，粉末的自熔性、潤濕性和噴焊性能好、耐高溫，耐
???????蝕、耐腐等特點。
?? 用途：噴焊或堆焊 ，適用于內燃機氣門錐面的耐高溫耐腐蝕預處理涂層，石油化工閥門、閥
????? 座、泵 密封面、轉子、活塞、拉桿、齒輪等零件的防磨、防腐及修復。
?? 粉末熔融溫度：980～1050°C
?? 噴焊沉積層硬度：HRC42～48
?? 粉末粒度范圍：－150～+320目（二步法）-150-+400目（一步法）-200目（真空熔燒）
?? 粉末化學成份：
| ?牌??號 | 化??學??成??份（ %） | ||||||||||||||||||||||||
|
|
|
|
| CO |
| |||||||||||||||||||
| Ni45A | 0.3－0.5 | 3－4.5 | 2－3.0 | 11－15 | ≤5.0 | 8-12 | 余??量 | ||||||||||||||||||
| Ni45 | 0.3－0.5 | 3－4.5 | 2－3.0 | 11－15 | ≤17 | ||||||||||||||||||||
| Category | Trade- | Chemical | Hardness | Application
|
| Oxy- 氧
乙
炔
焰
噴
焊 | F103 | Cr10 B1.5 Si3 Ni Rem. | HRc 25 | Spray-fusing of cast iron parts, such as die for glass, cylinder, and guide. |
| F101 | Cr10 B2.5 Si3 Ni Rem. | HRc 45 | Spray-fusing of parts resistance to wear and corrosion, such as valve, the rotator and piston of pump. | |
| F101Fe | Cr10 B2.5 Si3 Fe10 Ni Rem. | HRc 45 | Spray-fusing of corrosion-resistant parts, such as axle and stigma. | |
| F102 | Cr16 B4 Si4 Ni Rem. | HRc 60 | Spray-fusing of parts resistance to wear, corrosion and high temperature oxidation, such as die and piston. | |
| F102Fe | Cr16 B4 Si4 Fe15 Ni Rem. | HRc 60 | Spray-fusing of corrosion-resistant parts, such as axle and cold die. | |
| F105 | F102+50%WC | HRc 60 | Spray-fusing of parts resistance to grain-wear , such as guide plate, scraper and blade of fan. | |
| F105Fe | F102Fe+35%WC | HRc 60 | Spray-fusing of parts resistance to grain-wear, such as guide plate, scraper and blade of fan. | |
| F108 | F102+80%WC | HRc 60 | Spray-fusing of parts resistance to strong grain-wear and free machining, such as harrow teeth of dredger. | |
| F301 | Cr5 B4 Si4 Ni30 Fe Rem. | HRc 45 | Spray-fusing of vulnerable parts of agricultural machinery and mining machinery, such as gear and axletree. | |
| Track iron powder 軌鐵粉 | Cr5 B1.5 Si3 Ni30 Fe Rem. | HRc 28 | Repair spray-fusing of defects such as scratch and concavity of railroad track. | |
|
Oxy-acetylene flame spraying
氧 乙 炔 焰 噴 涂 | F111 | Cr5 B1.5 Si3 Ni30 Fe Rem. | HB 150 | Spraying of bearing and cutting parts etc. |
| F113 | Cr10 B1.5 Si3 Ni Rem. | HB 250 | Spray-fusing or spraying, such as roll, piston and axle of wear and corrosion resistance. | |
| F313 | Cr15 B1.5 Fe Rem. | HB 250 | Spraying of dryer of papermaking and axle. | |
| F314 | Cr18 Ni9 B1.5 Fe Rem. | HB 250 | Spraying of axle. | |
| F412 | Sn10 P0.3 Cu Rem. | HB 80 | Spraying of axle and bearing. | |
| F512 | 復合Al5Ni95 |
| Backing spray of transition layer between base and working layer. | |
|
PTA hardfacing 等 離 子 弧 噴 焊 | F221 | Cr26 W5 B0.7 Co Rem. | HRc 43 | PTA hardfacing of sealing surface of high temperature and high pressure valve and the edge of hot shearing tool. |
| F223 | Cr21 W5 B1.5 Co Rem. | HRc 40 | PTA hardfacing of parts resistance to wear and corrosion at high temperature, such as valve under high temperature and high pressure, and blower. | |
| F321 | Cr13 B1.5 Si1 Fe Rem. | HRc 45 | PTA hardfacing of corrosion-resistant parts under mid-temperature and mid-pressure, such as stop-plate etc. | |
| F322 | Cr23 Ni13 Si5 B1 Fe Rem. | HRc 40 | PTA hardfacing of corrosion-resistant parts under mid-temperature and mid-pressure, such as valve base etc. |
